| PCI |
0
|
| Serial-or-Paralel |
No/No
|
| Video-Connection |
HDMI/DP
|
| Wi-FI |
No
|
| CPU încorporat |
No
|
| Component for |
PC
|
| Wake-on-LAN ready |
Yes
|
| DisplayPort version |
1.4
|
| Ethernet interface type |
Gigabit Ethernet
|
| Memory channels |
Dual-channel
|
| Processor manufacturer |
Intel
|
| Maximum internal memory |
64 GB
|
| Ethernet LAN |
Yes
|
| HDMI ports quantity |
1
|
| HDMI version |
2.1
|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
0
|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
0
|
| USB 2.0 ports quantity |
4
|
| Audio output channels |
7.1 channels
|
| PCI Express x1 (Gen 3.x) slots |
1
|
| PCI Express x16 (Gen 4.x) slots |
1
|
| Number of memory slots |
2
|
| Supported storage drive types |
HDD & SSD
|
| Supported memory types |
DDR4-SDRAM
|
| LAN controller |
Realtek RTL8111H
|
| VGA (D-Sub) ports quantity |
1
|
| HDCP |
Yes
|
| DisplayPorts quantity |
1
|
| Maximum resolution |
7680 x 4320 pixels
|
| Parallel processing technology support |
Not supported
|
| DVI-D ports quantity |
0
|
| Windows operating systems supported |
Windows 10 x64, Windows 11 x64
|
| Drivers included |
Yes
|
| Model Chipset |
H610
|
| Gaming |
Nu
|
| Format: |
Micro-ATX (mATX)
|
| Soclu Procesor |
Socket 1700
|
| Tip Memorie |
DDR4
|
| Numar sloturi memorie |
2
|
| Memorie maxima |
64 GB
|
| Tip slot interfata grafica |
PCIe 4.0 x16
|
| Chipset audio integrat |
Realtek
|
| Canale audio |
7.1
|
| Wireless |
Nu
|
| Bluetooth |
Nu
|
| USB Type-C |
Da
|
| HDMI |
Da
|
| Thunderbolt |
Nu
|
| Sloturi M.2 |
N/A
|
| RJ-45 LAN |
1
|
| Memory slots type |
DIMM
|
| Unbuffered memory |
Yes
|
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
1
|
| USB 3.2 Gen 2 (3.1 Gen 2) connectors |
0
|
| Number of SATA III connectors |
4
|
| Front panel audio connector |
Yes
|
| ATX Power connector (24-pin) |
Yes
|
| CPU fan connector |
Yes
|
| PS/2 ports quantity |
1
|
| Motherboard form factor |
micro ATX
|
| BIOS type |
UEFI AMI
|
| ECC сompatibility |
ECC & Non-ECC
|
| TPM connector |
Yes
|
| Motherboard chipset family |
Intel
|
| System Management BIOS (SMBIOS) version |
2.7
|
| Processor socket |
LGA 1700
|
| Maximum number of SMP processors |
1
|
| 12V power connector |
Yes
|
| BIOS memory size |
128 Mbit
|
| Supported storage drive interfaces |
SATA III
|
| Chassis intrusion connector |
Yes
|
| USB 2.0 connectors |
1
|
| PC health monitoring |
CPU, Fan, Temperature, Voltage
|
| ACPI version |
6.0
|
| Number of chassis fan connectors |
1
|
| Motherboard chipset |
Intel H610
|
| Audio Chip |
Realtek ALC887 / Realtek ALC897
|
| Supported memory clock speeds |
3200 MHz
|
| Harmonized System (HS) code |
84733020
|
| Cables included |
SATA
|
| Width |
197 mm
|
| Depth |
18.8 mm
|
| Producator |
ASROCK
|
| Garantie |
36
|
|
