| LAN-Port-Type |
Gigabit
|
| Stackable |
Yes
|
| Plug and Play |
Yes
|
| Storage relative humidity (H-H) |
10 – 90%
|
| Jumbo frames support |
Yes
|
| Link aggregation |
Yes
|
| Rack mounting |
Yes
|
| VLAN support |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Web-based management |
Yes
|
| System event log |
Yes
|
| Switch type |
Managed
|
| 10G support |
Yes
|
| Port mirroring |
Yes
|
| Form factor |
1U
|
| MAC address filtering |
Yes
|
| Access Control List (ACL) |
Yes
|
| Power over Ethernet (PoE) |
No
|
| Switch layer |
L2
|
| Flow control support |
Yes
|
| Traffic shaping |
Yes
|
| Rate limiting |
Yes
|
| IGMP snooping |
Yes
|
| Rack mount kit |
Yes
|
| Installed SFP modules quantity |
0
|
| Broadcast storm control |
Yes
|
| Spanning tree protocol |
Yes
|
| Number of queues |
8
|
| Multicast support |
Yes
|
| Jumbo frames |
9000
|
| IP routing |
Yes
|
| MAC address table |
16000 entries
|
| Packet buffer memory |
1.5 MB
|
| SSH/SSL support |
Yes
|
| Safety |
LVD, BSMI
|
| Basic switching RJ-45 Ethernet ports quantity |
48
|
| ARP inspection |
Yes
|
| BPDU filtering/protection |
Yes
|
| Switching capacity |
176 Gbit/s
|
| DHCP features |
DHCP client
|
| Authentication |
MAC-based authentication
|
| MAC address auto-learning supported |
Yes
|
| Throughput |
130.9 Mpps
|
| Virtual LAN features |
Private VLAN, Protocol-based VLAN, Port-based VLAN
|
| Security algorithms |
802.1x RADIUS, SNMP, SSH, SSH-2
|
| Electromagnetic compatibility |
FCC 15 (A), CE (A), BSMI
|
| Mean time between failures (MTBF) |
970594 h
|
| Heat dissipation |
153.3 BTU/h
|
| Porturi RJ 45 |
28+
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
3-4
|
| Montare in Rack |
Da
|
| SFP module slots quantity |
4
|
| Management |
Da
|
| PoE |
Nu
|
| Cables included |
AC
|
| Certification |
RoHS
|
| Harmonized System (HS) code |
85176990
|
| Operating temperature (T-T) |
0 – 50 °C
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| Depth |
270 mm
|
| Operating relative humidity (H-H) |
10 – 95%
|
| Package width |
622 mm
|
| Width |
441 mm
|
| Height |
4.5 mm
|
| Package height |
108 mm
|
| Noise level |
44.15 dB
|
| Power consumption (max) |
45 W
|
| Weight |
3.86 kg
|
| Package depth |
358 mm
|
| Package weight |
4.92 kg
|
| Producator |
ZYXEL
|
| Garantie |
60
|
|
