| LAN-Port-Type |
Gigabit
|
| Stackable |
No
|
| Jumbo frames support |
Yes
|
| Link aggregation |
Yes
|
| Power supply included |
Yes
|
| Ethernet LAN data rates |
10,100,1000 Mbit/s
|
| Power over Ethernet (PoE) |
Yes
|
| Full duplex |
Yes
|
| VLAN support |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Static route |
Yes
|
| Web-based management |
Yes
|
| System event log |
Yes
|
| Switch type |
Managed
|
| Port mirroring |
Yes
|
| MAC address filtering |
Yes
|
| Access Control List (ACL) |
Yes
|
| Rack mounting |
No
|
| Basic switching RJ-45 Ethernet ports quantity |
8
|
| Flow control support |
Yes
|
| Power over Ethernet (PoE) type supported |
Active PoE, Passive PoE
|
| IGMP snooping |
Yes
|
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T
|
| Installed SFP modules quantity |
0
|
| Configuring Location Settings (CLI) |
Yes
|
| Console port |
RJ-45
|
| 10G support |
No
|
| Half duplex |
Yes
|
| Broadcast storm control |
Yes
|
| Spanning tree protocol |
Yes
|
| Auto-sensing |
Yes
|
| Virtual LAN features |
Private VLAN, Tagged VLAN, Voice VLAN
|
| Number of VLANs |
4093
|
| MAC address table |
16384 entries
|
| Number of queues |
8
|
| DHCP features |
DHCP server, DHCP snooping
|
| Security algorithms |
SSH-1.5, SSH-2, SSL/TLS
|
| Authentication |
Guest VLAN, Port-based authentication
|
| Authentication type |
IEEE 802.1x, RADIUS
|
| Multicast support |
Yes
|
| Management protocols |
SNMP v1/v2/v3, Telnet
|
| Power over Ethernet (PoE) power per port |
34.2 W
|
| Switching capacity |
20 Gbit/s
|
| Forwarding rate |
14.88 Mpps
|
| Gigabit Ethernet (copper) ports quantity |
8
|
| Porturi RJ 45 |
5-10
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
1-2
|
| Montare in Rack |
Da
|
| SFP module slots quantity |
2
|
| Management |
Da
|
| PoE |
Nu
|
| Harmonized System (HS) code |
85176990
|
| Depth |
235 mm
|
| Operating relative humidity (H-H) |
5 – 95%
|
| Width |
20.4 mm
|
| Height |
43 mm
|
| Weight |
1.72 kg
|
| Power consumption (max) |
150 W
|
| Certification |
ETSI300-019-1.4 CE, FCC, IC
|
| LED indicators |
Activity, LAN, PoE, Speed
|
| Operating temperature (T-T) |
-25 – 45 °C
|
| Producator |
UBIQUITI
|
| Garantie |
24
|
|
