| LAN-Port-Type |
Gigabit
|
| Storage relative humidity (H-H) |
5 – 90%
|
| Plug and Play |
Yes
|
| Jumbo frames support |
Yes
|
| Power supply included |
Yes
|
| Full duplex |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Power over Ethernet (PoE) |
No
|
| Rack mounting |
No
|
| Basic switching RJ-45 Ethernet ports quantity |
8
|
| Auto MDI/MDI-X |
Yes
|
| Flow control support |
Yes
|
| IGMP snooping |
Yes
|
| Output voltage |
9 V
|
| Jumbo frames |
16000
|
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T
|
| Auto-negotiation |
Yes
|
| Input current |
0.6 A
|
| Installed SFP modules quantity |
0
|
| 10G support |
No
|
| Switch type |
Unmanaged
|
| Packet buffer memory |
1.5 MB
|
| Cable types supported |
Cat3, Cat4, Cat5, Cat5e
|
| Store-and-forward |
Yes
|
| Gigabit Ethernet (copper) ports quantity |
8
|
| Switching capacity |
16 Gbit/s
|
| Forwarding rate |
11.9 Mpps
|
| Networking standards |
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
|
| MAC address table |
4000 entries
|
| Input voltage |
9 V
|
| Rubber feet |
Yes
|
| Porturi RJ 45 |
5-10
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
N/A
|
| Montare in Rack |
Nu
|
| Management |
Nu
|
| PoE |
Nu
|
| Operating temperature (T-T) |
0 – 40 °C
|
| Quick start guide |
Yes
|
| Cables included |
AC
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Harmonized System (HS) code |
85176990
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| LED indicators |
Yes
|
| Width |
158 mm
|
| Package type |
Box
|
| Height |
25.4 mm
|
| Package weight |
520 g
|
| Package depth |
130 mm
|
| Package height |
92 mm
|
| Wall mountable |
Yes
|
| Power source |
DC
|
| Certification |
CE, FCC, RoHS
|
| Package width |
191 mm
|
| Depth |
100.6 mm
|
| Power consumption (max) |
3.3 W
|
| Producator |
TP-LINK
|
| Garantie |
60
|
|
