| LAN-Port-Type |
Gigabit
|
| Storage relative humidity (H-H) |
5 – 90%
|
| Jumbo frames support |
Yes
|
| Link aggregation |
Yes
|
| Power over Ethernet (PoE) |
Yes
|
| Number of fans |
2 fan(s)
|
| Full duplex |
Yes
|
| Rack mounting |
Yes
|
| VLAN support |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Web-based management |
Yes
|
| Switch type |
Managed
|
| Port mirroring |
Yes
|
| Form factor |
1U
|
| Access Control List (ACL) |
Yes
|
| Internal memory |
256 MB
|
| Switch layer |
L2
|
| Auto MDI/MDI-X |
Yes
|
| Flow control support |
Yes
|
| Rate limiting |
Yes
|
| IGMP snooping |
Yes
|
| Auto-negotiation |
Yes
|
| Fiber optic connector |
SFP+
|
| Installed SFP modules quantity |
0
|
| Basic switching RJ-45 Ethernet ports quantity |
24
|
| Console port |
RJ-45
|
| 10G support |
No
|
| Spanning tree protocol |
Yes
|
| Number of queues |
8
|
| Multicast support |
Yes
|
| Jumbo frames |
9216
|
| IP routing |
Yes
|
| MAC address table |
16000 entries
|
| Packet buffer memory |
1.5 MB
|
| SSH/SSL support |
Yes
|
| Loop protection |
Yes
|
| Authentication |
Guest VLAN, MAC-based authentication, Port-based authentication
|
| Flash memory |
32 MB
|
| Traffic classification |
Yes
|
| Memory type |
DDR3-SDRAM
|
| BPDU filtering/protection |
Yes
|
| DHCP features |
DHCP client
|
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T
|
| Store-and-forward |
Yes
|
| Switching capacity |
56 Gbit/s
|
| Power over Ethernet (PoE) ports quantity |
24
|
| Number of VLANs |
4094
|
| IP-MAC-Port binding |
Yes
|
| Forwarding rate |
41.7 Mpps
|
| Access Control List (ACL) rules |
256
|
| Multicast Listener Discovery (MLD) snooping |
MLD v1, MLD v2
|
| Virtual LAN features |
MAC address-based VLAN, Port-based VLAN, Tagged VLAN, Voice VLAN
|
| Number of static routes |
32
|
| Security algorithms |
802.1x RADIUS, SNMP, SSH
|
| Electromagnetic compatibility |
FCC A, CE A, VCCI, C-Tick, BSMI, CCC
|
| Heat dissipation |
850.58 BTU/h
|
| Porturi RJ 45 |
24-28
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
3-4
|
| Montare in Rack |
Da
|
| SFP module slots quantity |
4
|
| Fiber ethernet cabling technology |
1000Base-X
|
| Management |
Da
|
| PoE |
Da
|
| Product colour |
Black, Grey
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Harmonized System (HS) code |
85176990
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| LED indicators |
Activity, Fan fail, Link, Power, Speed
|
| Depth |
210 mm
|
| Power source |
AC/DC
|
| Weight |
3.86 kg
|
| Noise level |
52.4 dB
|
| Power consumption (typical) |
27.49 W
|
| Certification |
IEC61000-4-5, RoHS
|
| Producator |
D-LINK
|
| Garantie |
60
|
|
