Name: Sursa GIGABYTE 850W UD850GM PG5, 80 PLUS GOLD - A.W.P.S Store
Brand: GIGABYTE
SKU: GP-UD850GM PG5W
Price: 638.33 RON
Availability: OutOfStock

Sursa GIGABYTE 850W UD850GM PG5, 80 PLUS GOLD

Adăugați preferateAdăugat la lista de preferințeEliminat din lista de dorințe 0

Sursa Gigabyte 850W UD850GM PG5, 80 PLUS GOLD, Active PFC (>0.9 typical), ATX 12V, Ventilator 120mm Hydraulic Bearing, Alb

Specificație: Sursa GIGABYTE 850W UD850GM PG5, 80 PLUS GOLD

PSU Type	ATX
Number of fans	1 fan(s)
Purpose	PC
Fan diameter	12 cm
Peripheral (Molex) power connectors (4-pin)	3
Mean time between failures (MTBF)	100000 h
Conectivitate	Full – Modular
Iluminare RGB	Nu
Certificare 80 Plus	80 PLUS Gold
Motherboard power connector	20+4 pin ATX
EPS power connector (4+4 pin)	Yes
PCI Express power connectors (6+2 pin)	4
CPU power connector (4+4 pin)	Yes
CPU power cable length	60 cm
ATX power connector (20+4 pin)	Yes
Power supply unit (PSU) form factor	ATX
Fan location	Top
Combined power (+5Vsb)	15 W
Max output current (+5Vsb)	3 A
Number of SATA power connectors	8
Motherboard power cable length	61 cm
Cabling type	Fully-Modular
Power Factor Correction (PFC) type	Active
Max output current (+3.3V)	20 A
Max output current (+5V)	20 A
Floppy drive power connector	1
Floppy disk drive connector	Yes
80 PLUS certification	80 PLUS Gold
Efficiency	90%
Hold time	16 ms
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
ATX version	2.31
Total power	850 W
PCI Express power cable length	60 cm
Bearing technology	HYB
Combined power (+3.3V)	105 W
Input current	12 A
Combined power (+12V)	732 W
Combined power (+5V)	105 W
Max output current (+12V)	2.3 A
SATA power cable length	150,300,450,600 mm
Peripheral (Molex) power cable length	120,500 mm
Floppy disk drive cable length	15 cm
PSU-Power	850 W
PFC	Active
Width	150 mm
Harmonized System (HS) code	84733020
Height	86 mm
Cables included	CPU, PCIe, Peripheral (Molex), SATA
On/off switch	Yes
Depth	140 mm
Producator	GIGABYTE
Garantie	36
