Name: Sursa Gigabyte 750W UD750GM PG5 80 PLUS GOLD - A.W.P.S Store
Brand: GIGABYTE
SKU: GP-UD750GM PG5
Price: 615.60 RON
Availability: OutOfStock

Sursa Gigabyte 750W UD750GM PG5 80 PLUS GOLD

Adăugați preferateAdăugat la lista de preferințeEliminat din lista de dorințe 0

Sursa Gigabyte 750W UD750GM PG5, 80 PLUS GOLD, Active PFC (>0.9 typical), ATX 12V, Ventilator 120mm Hydraulic Bearing, Protectii OVP, OPP, SCP, UVP, OCP, OTP, Negru

Specificație: Sursa Gigabyte 750W UD750GM PG5 80 PLUS GOLD

PSU Type	ATX
Number of fans	1 fan(s)
Purpose	PC
Fan diameter	12 cm
Peripheral (Molex) power connectors (4-pin)	3
Mean time between failures (MTBF)	100000 h
Conectivitate	Full – Modular
Iluminare RGB	Nu
Certificare 80 Plus	80 PLUS Gold
Motherboard power connector	20+4 pin ATX
EPS power connector (4+4 pin)	Yes
PCI Express power connectors (6+2 pin)	4
CPU power connector (4+4 pin)	Yes
CPU power cable length	60 cm
ATX power connector (20+4 pin)	Yes
Power supply unit (PSU) form factor	ATX
Fan location	Top
Total power	750 W
Combined power (+5Vsb)	15 W
Max output current (+5Vsb)	3 A
Number of SATA power connectors	8
Motherboard power cable length	61 cm
Cabling type	Fully-Modular
Power Factor Correction (PFC) type	Active
Max output current (+3.3V)	20 A
Max output current (+5V)	20 A
Floppy drive power connector	1
Floppy disk drive connector	Yes
80 PLUS certification	80 PLUS Gold
Efficiency	90%
Hold time	16 ms
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
ATX version	2.31
PCI Express power cable length	60 cm
Bearing technology	HYB
Combined power (+3.3V)	105 W
Input current	12 A
Combined power (+12V)	732 W
Combined power (+5V)	105 W
Max output current (+12V)	2.3 A
SATA power cable length	150,300,450,600 mm
Peripheral (Molex) power cable length	120,500 mm
Floppy disk drive cable length	15 cm
PSU-Power	750 W
PFC	Active
Width	150 mm
Harmonized System (HS) code	84733020
Height	86 mm
Cables included	CPU, PCIe, Peripheral (Molex), SATA
On/off switch	Yes
Depth	140 mm
Producator	GIGABYTE
Garantie	120
