Name: Placa de bază Gigabyte Z890 EAGLE WIFI7 LGA1851 - A.W.P.S Store
Brand: GIGABYTE
SKU: Z890 EAGLE WIFI7
Price: 1186.25 RON
Availability: OutOfStock

Placa de bază Gigabyte Z890 EAGLE WIFI7 LGA1851

Adăugați preferateAdăugat la lista de preferințeEliminat din lista de dorințe 0

Placa de Baza GIGABYTE Z890 EAGLE WIFI7 LGA1851, 4x DDR5, 1x DP, 3x PCIE x16, 4x M.2, 4x SATA III, ATX

Specificație: Placa de bază Gigabyte Z890 EAGLE WIFI7 LGA1851

PCI	0
Serial-or-Paralel	Yes/No
Video-Connection	HDMI/DP
Wi-FI	Yes
USB3	4-8
Onboard-CPU	No
RAID support	Yes
Component for	PC
Thunderbolt ports quantity	2
Memory channels	Dual-channel
Processor manufacturer	Intel
Ethernet LAN	Yes
HDMI ports quantity	1
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
USB 2.0 ports quantity	4
Audio output channels	7.1 channels
DisplayPorts quantity	2
PCI Express x16 (Gen 5.x) slots	1
On-board graphics card	No
Supported storage drive types	HDD & SSD
S/PDIF out port	Yes
PCI Express x16 (Gen 4.x) slots	2
VGA (D-Sub) ports quantity	0
DVI-D ports quantity	0
DirectX version	12.0
Model Chipset	Z890
Gaming	Nu
Format:	ATX
Soclu Procesor	Socket 1851
Tip Memorie	DDR5
Numar sloturi memorie	4
Memorie maxima	256 GB
Tip slot interfata grafica	N/A
Chipset audio integrat	Realtek
Canale audio	7.1
Wireless	Da
Bluetooth	Da
USB Type-C	Da
HDMI	Da
Thunderbolt	Nu
Sloturi M.2	4
RJ-45 LAN	1
Number of memory slots	4
Memory slots type	DIMM
Supported storage drive interfaces	M.2, SATA III
USB 2.0 connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
Number of SATA III connectors	4
Number of SATA II connectors	0
Number of SATA connectors	0
ATX Power connector (24-pin)	Yes
EPS power connector (8-pin)	Yes
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
Clear CMOS jumper	Yes
mSATA ports quantity	0
Processor socket	LGA 1851 (Socket V1)
Supported processor sockets	LGA 1851
Supported memory types	DDR5-SDRAM
Maximum internal memory	256 GB
RAID levels	0, 1, 5, 10
USB 3.2 Gen 2 (3.1 Gen 2) connectors	1
TPM connector	Yes
RGB LED pin header	Yes
Ethernet interface type	2.5 Gigabit Ethernet
Motherboard form factor	ATX
Motherboard chipset family	Intel
Windows operating systems supported	Windows 11 x64
ACPI version	5.0
Desktop Management Interface (DMI) version	2.7
System Management BIOS (SMBIOS) version	2.7
Lithium weight per battery	0.07 g
Total number of SATA connectors	4
12V power connector	Yes
Clear CMOS button	Yes
ECC сompatibility	Non-ECC
Compatible processor series	Intel Core Ultra (Series 2)
Motherboard chipset	Intel Z890
Number of M.2 (M) slots	4
PC health monitoring	Fan, Temperature, Voltage
Maximum internal memory supported by processor	256 GB
WLAN controller model	MediaTek MT7925
Audio Chip	Realtek ALC1220
Supported memory module capacities	1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 24GB, 32GB, 40GB, 48GB, 64GB
Number of HDDs supported	8
Number of storage drives supported	4
Supported memory clock speeds	5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800,7900,7950,8000,8266,8400,8600 MHz
MB-Format	ATX
PCI-Ex1	0
PCI-Ex16	3
RAM-Slots	4
MB-Socket	LGA1851
Microphone in	Yes
Wi-Fi standards	Wi-Fi 7 (802.11be)
Bluetooth version	5.4
Height	35 mm
Width	305 mm
Depth	244 mm
Weight	1.78 kg
Country of origin	China
Battery weight	3 g
Number of battery cells	1
Battery technology	Lithium-Manganese Dioxide (LiMnO2)
Battery type	CR2032
Package width	335 mm
Package depth	270 mm
Package height	80 mm
Package weight	2.02 kg
Bundled software	Norton® Internet Security (OEM version); LAN bandwidth management software
Producator	GIGABYTE
Garantie	36
