Name: SOCOMEC ITYS 1000VA VFI UPS 1/1 PF=1 WITH BATTERY - A.W.P.S Store
Brand: SOCOMEC
SKU: ITY3-TW010B
Price: 1754.16 RON
Availability: InStock

SOCOMEC ITYS 1000VA VFI UPS 1/1 PF=1 WITH BATTERY

Adăugați preferateAdăugat la lista de preferințeEliminat din lista de dorințe 0

SOCOMEC ITYS 1000VA VFI UPS 1/1 PF=1 WITH BATTERY INTEGRATED

– Embedded dry-contact interface.
– Input mains switch breaker.
– Connection for battery extension modules.
– Power off the UPS remotely.
– Internal temperature sensor.

Input connection C14
Number of output connections C13 4 pcs

Specificație: SOCOMEC ITYS 1000VA VFI UPS 1/1 PF=1 WITH BATTERY

USB Port	Yes
ECO mode	Yes
RS-232 ports	1
Capacitate putere UPS	1000W
Tip UPS:	Online
Capacitate Rack:	None
Ecran LCD:	Da
Port USB	Da
Output frequency	50/60 Hz
Number of input phases	1
Number of output phases	1
Efficiency (ECO mode)	98%
AC outlet types	C13 coupler
Power plug	C14 coupler
USB port type	USB Type-B
Form factor	Mini Tower
Safety	IEC/EN 62040-1, AS 62040.1.1, AS 62040.1.2
Waveform	Sine
Input operation voltage (max)	300 V
Output operation voltage (max)	240 V
Emergency Power Off (EPO)	Yes
Output power capacity	1 kVA
Battery capacity	7 Ah
UPS topology	Double-conversion (Online)
Input frequency	40 – 70 Hz
Crest factor	3:1
Output operation voltage (min)	200 V
Efficiency	93%
Input power factor	0.99
AC outlets quantity	4 AC outlet(s)
Input operation voltage (min)	160 V
Output power	1000 W
Output power factor	1
Power protection features	Short circuit
Typical backup time at full load	7.8 min
Charging current	8 A
Operating altitude	0 – 1000 m
Battery technology	Sealed Lead Acid (VRLA)
Operating temperature (T-T)	0 – 45 °C
Operating relative humidity (H-H)	0 – 95%
LED indicators	Yes
Country of origin	China
Display type	LCD
Control type	Buttons
Height	22.4 mm
Noise level	50 dB
International Protection (IP) code	IP20
Battery life (max)	3 year(s)
Weight	14.4 kg
Depth	40.4 mm
Battery voltage	3.6 V
Product colour	Black, Grey, Orange
Width	14.5 mm
Certification	IEC/EN 62040-2, AS 62040.2 IEC/EN 62040-3 CE, RCM (E2376)
Producator	SOCOMEC
Garantie	24
