APC Easy UPS BVX 700VA – 230V – AVR – Schuko Sockets

APC Easy UPS BVX 700VA, 230V, AVR,Schuko Sockets

Easy UPS provides power protection for unstable power conditions, ensuring consistent and reliable connectivity at the most critical moments.

Includes: User manual

Output power capacity

360 Watts / 700VA

Nominal Output Voltage

230V

Nominal Input Voltage

230V

Input Connections

Schuko

Cord Length

1.2meters

Max Configurable Power (Watts)

360 Watts / 700VA

Output Frequency (sync to mains)

50/60 Hz +/- 1 Hz Sync to mains

Topology

Line interactive

Waveform type

Stepped approximation to a sinewave

Transfer Time

6 ms typical : 10 ms maximum

Specificație: APC Easy UPS BVX 700VA – 230V – AVR – Schuko Sockets

Operating altitude	0 – 3000 m
Response time	6 ms
Power plug	Type F
Surge protection	Yes
Audible alarm(s)	Yes
Tip UPS:	Line Interactive
Capacitate putere UPS	400W
Capacitate Rack:	None
Ecran LCD:	Nu
Port USB	Nu
UPS topology	Line-Interactive
Input operation voltage (min)	170 V
Input operation voltage (max)	280 V
Output frequency	50/60 Hz
Waveform	Sine
AC outlet types	Type F
Cold start	Yes
Automatic Voltage Regulation (AVR)	Yes
Output voltage regulation	10%
Battery capacity	7 Ah
Output power	360 W
Output operation voltage (max)	230 V
Form factor	Compact
Output operation voltage (min)	230 V
Output frequency regulation	0.5 Hz
Surge energy rating	273 J
AC outlets quantity	2 AC outlet(s)
Audible alarm modes	Alarm when on battery, Battery replacement, Low battery alarm, Overload alarm
Non-operating altitude	0 – 3000 m
Output power capacity	0.7 kVA
Input power factor	0.51
Operating temperature (T-T)	0 – 40 °C
Battery technology	Sealed Lead Acid (VRLA)
Battery voltage	12 V
Operating relative humidity (H-H)	0 – 95%
LED indicators	Yes
Harmonized System (HS) code	85078000
Weight	4.5 kg
Width	31 mm
Package width	222 mm
Package weight	4.5 kg
Cables included	Input power cable
Battery recharge time	8 h
Storage temperature (T-T)	-15 – 40 °C
Noise level	40 dB
Battery life (max)	2 year(s)
International Protection (IP) code	IP20
Certification	CB, CE, EN/IEC 62040-1, EN/IEC 62040-2
Package depth	346 mm
Depth	138 mm
Height	98 mm
Package height	142 mm
Producator	APC
Garantie	24
