APC Easy UPS BVX 2200VA – 230V – AVR – Schuko Sockets

APC Easy UPS BVX 2200VA, 230V, AVR, Schuko Sockets

Easy UPS provides power protection for unstable power conditions, ensuring consistent and reliable connectivity at the most critical moments.

Includes: User manual

Output power capacity

1.2kWatts / 2.2kVA

Nominal Output Voltage

230V

Nominal Input Voltage

230V

Input Connections

Schuko

Cord Length

1.2meters

Max Configurable Power (Watts)

1.2kWatts / 2.2kVA

Output Frequency (sync to mains)

50/60 Hz +/- 1 Hz Sync to mains

Topology

Line interactive

Waveform type

Stepped approximation to a sinewave

Transfer Time

6 ms typical : 10 ms maximum

Specificație: APC Easy UPS BVX 2200VA – 230V – AVR – Schuko Sockets

Operating altitude	0 – 3000 m
Capacitate putere UPS	1200W
Response time	6 ms
Power plug	Type F
Audible alarm(s)	Yes
Tip UPS:	Line Interactive
Capacitate Rack:	None
Ecran LCD:	Nu
Port USB	Nu
UPS topology	Line-Interactive
Output frequency	50/60 Hz
Waveform	Sine
Input operation voltage (max)	300 V
AC outlet types	Type F
Cold start	Yes
Automatic Voltage Regulation (AVR)	Yes
Output power capacity	2.2 kVA
AC outlets quantity	4 AC outlet(s)
Input operation voltage (min)	140 V
Surge energy rating	273 J
Output power	1200 W
Battery capacity	9 Ah
Non-operating altitude	0 – 3000 m
Form factor	N/A
Operating temperature (T-T)	0 – 40 °C
Width	140 mm
Height	190 mm
Operating relative humidity (H-H)	0 – 95%
LED indicators	Yes
Harmonized System (HS) code	85078000
Cable length	1.2 m
Package depth	235 mm
Cables included	Input power cable
Battery recharge time	8 h
Storage temperature (T-T)	-15 – 40 °C
Depth	390 mm
Certification	CE, EN/IEC 62040-1, EN/IEC 62040-2
Package height	297 mm
International Protection (IP) code	IP20
Battery voltage	24 V
Weight	12.2 kg
Package weight	13.2 kg
Battery technology	Lead-Acid
Battery life (max)	3 year(s)
Package width	495 mm
Producator	APC
Garantie	24
