| LAN-Port-Type |
Gigabit
|
| Link aggregation |
Yes
|
| Rack mounting |
Yes
|
| VLAN support |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Web-based management |
Yes
|
| System event log |
Yes
|
| Switch type |
Managed
|
| Port mirroring |
Yes
|
| MAC address filtering |
Yes
|
| Access Control List (ACL) |
Yes
|
| Internal memory |
256 MB
|
| Power over Ethernet (PoE) |
No
|
| Switch layer |
L2
|
| Flow control support |
Yes
|
| Rate limiting |
Yes
|
| IGMP snooping |
Yes
|
| Storage relative humidity (H-H) |
10 – 95%
|
| Fiber optic connector |
SFP+
|
| Fiber ports quantity |
2
|
| Installed SFP modules quantity |
0
|
| Configuring Location Settings (CLI) |
Yes
|
| 10G support |
No
|
| Broadcast storm control |
Yes
|
| Spanning tree protocol |
Yes
|
| Authentication type |
IEEE 802.1x, RADIUS
|
| Multicast support |
Yes
|
| MAC address table |
16000 entries
|
| Packet buffer memory |
1.5 MB
|
| Flash memory |
32 MB
|
| Combo SFP ports quantity |
4
|
| Copper ethernet cabling technology |
10BASE-TX, 1000BASE-T
|
| Virtual LAN features |
Port-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN
|
| DHCP features |
DHCP client, DHCP relay, DHCP snooping, DHCPv6 client, DHCPv6 relay
|
| Security algorithms |
SNMP, SNMPv2, SNMPv3, SSH-2, SSL/TLS
|
| Authentication |
Guest VLAN, MAC-based authentication
|
| Switching capacity |
100 Gbit/s
|
| Forwarding rate |
7.4 Mpps
|
| Basic switching RJ-45 Ethernet ports quantity |
44
|
| Mean time between failures (MTBF) |
660245 h
|
| Heat dissipation |
125.829 BTU/h
|
| Porturi RJ 45 |
28+
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
1-2
|
| Montare in Rack |
Da
|
| Fiber ethernet cabling technology |
1000Base-X
|
| Management |
Da
|
| PoE |
Nu
|
| Cables included |
AC
|
| Harmonized System (HS) code |
85176990
|
| Operating temperature (T-T) |
0 – 50 °C
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| Operating relative humidity (H-H) |
10 – 95%
|
| Package height |
90 mm
|
| Depth |
200 mm
|
| Weight |
2.9 kg
|
| Height |
44.5 mm
|
| Certification |
LVD, BSMI FCC 15 A, CE EMC A, BSMI ENC RoHS A
|
| Power consumption (max) |
36.9 W
|
| Package width |
496 mm
|
| Package depth |
289 mm
|
| Package weight |
3.97 kg
|
| Noise level |
47.3 dB
|
| Producator |
ZYXEL
|
| Garantie |
60
|
|
