| LAN-Port-Type |
Gigabit
|
| Storage relative humidity (H-H) |
5 – 90%
|
| Jumbo frames support |
Yes
|
| Link aggregation |
Yes
|
| Ethernet LAN data rates |
10,100,1000 Mbit/s
|
| Number of fans |
0 fan(s)
|
| Rack mounting |
Yes
|
| VLAN support |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Static route |
Yes
|
| Web-based management |
Yes
|
| System event log |
Yes
|
| Switch type |
Managed
|
| Port mirroring |
Yes
|
| Form factor |
1U
|
| Policy-based routing |
Yes
|
| MAC address filtering |
Yes
|
| Access Control List (ACL) |
Yes
|
| Power over Ethernet (PoE) |
No
|
| Flow control support |
Yes
|
| Rate limiting |
Yes
|
| IGMP snooping |
Yes
|
| Power supply included |
No
|
| Installed SFP modules quantity |
0
|
| Configuring Location Settings (CLI) |
Yes
|
| Basic switching RJ-45 Ethernet ports quantity |
24
|
| Gigabit Ethernet (copper) ports quantity |
24
|
| 10G support |
No
|
| Broadcast storm control |
Yes
|
| Spanning tree protocol |
Yes
|
| Multicast support |
Yes
|
| Jumbo frames |
9000
|
| IP routing |
Yes
|
| Number of VLANs |
4000
|
| MAC address table |
16000 entries
|
| SSH/SSL support |
Yes
|
| Loop protection |
Yes
|
| GARP VLAN Registration Protocol (GVRP) |
Yes
|
| ARP inspection |
Yes
|
| BPDU filtering/protection |
Yes
|
| Store-and-forward |
Yes
|
| Switching capacity |
56 Gbit/s
|
| Packet buffer memory |
12 MB
|
| Head-of-line (HOL) blocking |
Yes
|
| Static port security |
Yes
|
| Number of static routes |
48
|
| DHCP features |
DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping
|
| IP-MAC-Port binding |
Yes
|
| Authentication |
MAC-based authentication, Port-based authentication
|
| Multicast Listener Discovery (MLD) snooping |
Y
|
| Management protocols |
SNMPv1/v2c/v3, SNTP
|
| Authentication type |
AAA, RADIUS, TACACS+
|
| IPv4 routes |
48
|
| IPv6 routes |
48
|
| IPv4 & IPv6 features |
IPv4/IPv6 access-control list (ACL), IPv6 Telnet, IPv6 ping, IPv6 tracert
|
| MIB support |
Yes
|
| Networking standards |
IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3z
|
| Forwarding rate |
41.66 Mpps
|
| Virtual LAN features |
Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
|
| Heat dissipation |
70.3 BTU/h
|
| Porturi RJ 45 |
24-28
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
3-4
|
| Montare in Rack |
Da
|
| SFP module slots quantity |
4
|
| Console port |
RJ-45/micro-USB
|
| Management |
Da
|
| PoE |
Nu
|
| Quick start guide |
Yes
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Depth |
180 mm
|
| Operating temperature (T-T) |
0 – 45 °C
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| LED indicators |
Yes
|
| Power source |
AC
|
| Cables included |
LAN (RJ-45)
|
| Cloud-managed |
Yes
|
| Power consumption (max) |
20.6 W
|
| Producator |
TP-LINK
|
| Garantie |
60
|
|
