| LAN-Port-Type |
Gigabit
|
| Storage relative humidity (H-H) |
5 – 90%
|
| Jumbo frames support |
Yes
|
| Link aggregation |
Yes
|
| Power supply included |
Yes
|
| Power over Ethernet (PoE) |
Yes
|
| VLAN support |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Web-based management |
Yes
|
| Switch type |
Managed
|
| Port mirroring |
Yes
|
| MAC address filtering |
Yes
|
| Access Control List (ACL) |
Yes
|
| Switch layer |
L2
|
| Basic switching RJ-45 Ethernet ports quantity |
8
|
| Flow control support |
Yes
|
| Rate limiting |
Yes
|
| IGMP snooping |
Yes
|
| Fiber optic connector |
SFP+
|
| Fiber ports quantity |
2
|
| Installed SFP modules quantity |
0
|
| Console port |
RJ-45
|
| 10G support |
No
|
| Broadcast storm control |
Yes
|
| Spanning tree protocol |
Yes
|
| Multicast support |
Yes
|
| MAC address table |
8000 entries
|
| Jumbo frames |
9000
|
| Fanless |
Yes
|
| Number of VLANs |
4000
|
| SSH/SSL support |
Yes
|
| MIB support |
Y
|
| Copper ethernet cabling technology |
1000BASE-T, 1000BASE-TX, 10BASE-T
|
| Virtual LAN features |
MAC address-based VLAN, Multicast VLAN, Protocol-based VLAN, Voice VLAN
|
| Fiber ethernet cabling technology |
1000BASE-X, 100BASE-FX
|
| Fiber type |
Multi-mode
|
| Switching capacity |
20 Gbit/s
|
| Forwarding rate |
14.88 Mpps
|
| Number of queues |
4
|
| Packet buffer memory |
4.1 MB
|
| DHCP features |
DHCP client, DHCP snooping, DHCPv6 client, DHCPv6 snooping
|
| Security algorithms |
SNMP, SSH, SSH-2
|
| BPDU filtering/protection |
Yes
|
| Power over Ethernet plus (PoE+) ports quantity |
8
|
| Total Power over Ethernet (PoE) budget |
58 W
|
| Porturi RJ 45 |
5-10
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
1-2
|
| Montare in Rack |
Nu
|
| SFP module slots quantity |
2
|
| Management |
Da
|
| PoE |
Da
|
| Operating temperature (T-T) |
0 – 40 °C
|
| Quick start guide |
Yes
|
| Cables included |
AC
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Harmonized System (HS) code |
85176990
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| Width |
20.9 mm
|
| Power source |
AC
|
| Package weight |
1.25 kg
|
| Package height |
70 mm
|
| Height |
26 mm
|
| Package width |
240 mm
|
| Package depth |
315 mm
|
| Certification |
CE, FCC, RoHS
|
| Depth |
126 mm
|
| LED indicators |
Link, PoE, Power
|
| Power consumption (max) |
75.3 W
|
| Producator |
TP-LINK
|
| Garantie |
24
|
|
