| LAN-Port-Type |
Gigabit
|
| Storage relative humidity (H-H) |
5 – 90%
|
| Jumbo frames support |
Yes
|
| Link aggregation |
Yes
|
| Power supply included |
Yes
|
| Power over Ethernet (PoE) |
Yes
|
| Rack mounting |
Yes
|
| VLAN support |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Web-based management |
Yes
|
| System event log |
Yes
|
| Switch type |
Managed
|
| Port mirroring |
Yes
|
| Security algorithms |
802.1x RADIUS
|
| MAC address filtering |
Yes
|
| Basic switching RJ-45 Ethernet ports quantity |
8
|
| Auto MDI/MDI-X |
Yes
|
| Flow control support |
Yes
|
| Rate limiting |
Yes
|
| IGMP snooping |
Yes
|
| Auto-negotiation |
Yes
|
| Installed SFP modules quantity |
0
|
| 10G support |
No
|
| Broadcast storm control |
Yes
|
| Spanning tree protocol |
Yes
|
| Number of queues |
8
|
| Multicast support |
Yes
|
| MAC address table |
8000 entries
|
| Jumbo frames |
9000
|
| Fanless |
Yes
|
| Authentication type |
RADIUS
|
| ARP inspection |
Yes
|
| Packet buffer memory |
4.1 MB
|
| Switching capacity |
16 Gbit/s
|
| Forwarding rate |
11.9 Mpps
|
| Number of VLANs |
4094
|
| IPv4 & IPv6 features |
IPv6 Telnet, IPv6 ping, IPv6 tracert
|
| Authentication |
MAC-based authentication, Web-based authentication
|
| Switch layer |
L2/L2+
|
| Power over Ethernet plus (PoE+) ports quantity |
4
|
| DHCP features |
DHCP client, DHCP relay, DHCP snooping, DHCPv6 server, DHCPv6 snooping
|
| Management protocols |
SNMPv1/v2c/v3
|
| Heat dissipation |
263.6 BTU/h
|
| Porturi RJ 45 |
5-10
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
N/A
|
| Montare in Rack |
Nu
|
| Management |
Da
|
| PoE |
Da
|
| Operating temperature (T-T) |
0 – 40 °C
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| LED indicators |
Yes
|
| Width |
20.9 mm
|
| Package type |
Box
|
| Height |
26 mm
|
| Certification |
CE, FCC, RoHS
|
| Depth |
126 mm
|
| Power consumption (max) |
77.3 W
|
| Producator |
TP-LINK
|
| Garantie |
24
|
|
