| LAN-Port-Type |
Gigabit
|
| Storage relative humidity (H-H) |
5 – 90%
|
| Power supply included |
Yes
|
| Power over Ethernet (PoE) |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Auto MDI/MDI-X |
Yes
|
| IGMP snooping |
Yes
|
| Basic switching RJ-45 Ethernet ports quantity |
9
|
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T
|
| Auto-negotiation |
Yes
|
| 10G support |
No
|
| Switch type |
Unmanaged
|
| Fanless |
Yes
|
| Switching capacity |
20 Gbit/s
|
| Power over Ethernet plus (PoE+) ports quantity |
8
|
| MAC address auto-aging supported |
Yes
|
| Store-and-forward |
Yes
|
| MAC address table |
4000 entries
|
| MAC address auto-learning supported |
Yes
|
| DC input voltage |
53.5 V
|
| Input current |
1.31 A
|
| Packet buffer memory |
14.88 MB
|
| Gigabit Ethernet (copper) ports quantity |
9
|
| Networking standards |
IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
|
| Fiber type |
Single-mode
|
| Total Power over Ethernet (PoE) budget |
63 W
|
| Heat dissipation |
266.42 BTU/h
|
| Porturi RJ 45 |
5-10
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
1-2
|
| Montare in Rack |
Nu
|
| SFP module slots quantity |
1
|
| Fiber ethernet cabling technology |
1000Base-X
|
| Management |
Nu
|
| PoE |
Da
|
| Quick start guide |
Yes
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Harmonized System (HS) code |
85176990
|
| Operating temperature (T-T) |
0 – 50 °C
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| LED indicators |
Yes
|
| Housing material |
Metal
|
| Package weight |
1.24 kg
|
| Package height |
70 mm
|
| Power source |
DC
|
| Height |
26 mm
|
| Package width |
240 mm
|
| Package depth |
315 mm
|
| Certification |
CE, FCC, RoHS
|
| Depth |
126 mm
|
| Power consumption (max) |
78.13 W
|
| Width |
209 mm
|
| Producator |
TP-LINK
|
| Garantie |
60
|
|
