| LAN-Port-Type |
Gigabit
|
| Storage relative humidity (H-H) |
5 – 90%
|
| Jumbo frames support |
Yes
|
| Link aggregation |
Yes
|
| Power supply included |
Yes
|
| Input voltage |
5 V
|
| VLAN support |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Web-based management |
Yes
|
| Switch type |
Managed
|
| Port mirroring |
Yes
|
| Power over Ethernet (PoE) |
No
|
| Gigabit Ethernet (copper) ports quantity |
5
|
| Switch layer |
L2
|
| Auto MDI/MDI-X |
Yes
|
| IGMP snooping |
Yes
|
| Jumbo frames |
16000
|
| Auto-negotiation |
Yes
|
| Input current |
0.6 A
|
| Rack mount kit |
Yes
|
| Networking standards |
IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
|
| Installed SFP modules quantity |
0
|
| 10G support |
No
|
| Basic switching RJ-45 Ethernet ports quantity |
5
|
| Cable types supported |
Cat3, Cat4, Cat5, Cat5e, Cat6
|
| MAC address table |
2000 entries
|
| Store-and-forward |
Yes
|
| Copper ethernet cabling technology |
1000BASE-T, 100BASE-TX, 10BASE-T
|
| Switching capacity |
10 Gbit/s
|
| Forwarding rate |
7.44 Mpps
|
| Packet buffer memory |
1 MB
|
| Virtual LAN features |
Port-based VLAN
|
| Number of VLANs |
32
|
| Compatible operating systems |
Microsoft Windows XP, Vista Windows 7, Windows 8, MAC OS, NetWare, UNIX / Linux
|
| Heat dissipation |
9.07 BTU/h
|
| Porturi RJ 45 |
5-10
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
N/A
|
| Montare in Rack |
Nu
|
| Management |
Nu
|
| PoE |
Nu
|
| Operating temperature (T-T) |
0 – 40 °C
|
| Quick start guide |
Yes
|
| Cables included |
AC
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Depth |
98 mm
|
| Width |
100 mm
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| LED indicators |
Yes
|
| Package type |
Box
|
| Height |
25 mm
|
| Package height |
92 mm
|
| Package depth |
128 mm
|
| Power source |
DC
|
| Certification |
FCC, CE, RoHS
|
| Package width |
125 mm
|
| Package weight |
450 g
|
| Power consumption (max) |
2.82 W
|
| Producator |
TP-LINK
|
| Garantie |
60
|
|
