| LAN-Port-Type |
Gigabit
|
| Storage relative humidity (H-H) |
5 – 90%
|
| Jumbo frames support |
Yes
|
| Number of fans |
2 fan(s)
|
| Full duplex |
Yes
|
| Rack mounting |
Yes
|
| Form factor |
1U
|
| Auto MDI/MDI-X |
Yes
|
| Flow control support |
Yes
|
| Auto-negotiation |
Yes
|
| Rack mount kit |
Yes
|
| Installed SFP modules quantity |
0
|
| 10G support |
No
|
| Half duplex |
Yes
|
| MAC address table |
8000 entries
|
| Switch type |
Unmanaged
|
| Basic switching RJ-45 Ethernet ports quantity |
48
|
| Store-and-forward |
Yes
|
| Cable types supported |
Cat3, Cat5, Cat6
|
| Jumbo frames |
10000
|
| Packet buffer memory |
16 MB
|
| Networking standards |
IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
|
| Rubber feet |
Yes
|
| Copper ethernet cabling technology |
10BASE-T, 100BASE-T, 100BASE-X, 1000BASE-T
|
| Switching capacity |
96 Gbit/s
|
| Throughput |
71.4 Mpps
|
| Compatible operating systems |
Microsoft Windows 2000/XP/2003/Vista/2008/7/2012/8/10 MacOS NetWare UNIX Linux
|
| Heat dissipation |
110.17 BTU/h
|
| Porturi RJ 45 |
28+
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
N/A
|
| Montare in Rack |
Nu
|
| Management |
Nu
|
| PoE |
Nu
|
| Operating temperature (T-T) |
0 – 40 °C
|
| Quick start guide |
Yes
|
| Cables included |
AC
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| Package height |
100 mm
|
| Depth |
220 mm
|
| Power source |
AC
|
| Certification |
FCC, CE, RoHS
|
| Package weight |
4.18 kg
|
| Package depth |
528 mm
|
| Package width |
336 mm
|
| Power consumption (max) |
29.8 W
|
| Producator |
TP-LINK
|
| Garantie |
60
|
|
