| LAN-Port-Type |
FastEthernet
|
| Stackable |
No
|
| Storage relative humidity (H-H) |
5 – 90%
|
| Power supply included |
Yes
|
| Rack mounting |
Yes
|
| Ethernet LAN data rates |
10,100 Mbit/s
|
| Power over Ethernet (PoE) |
No
|
| Auto MDI/MDI-X |
Yes
|
| Rack mount kit |
Yes
|
| Supported network protocols |
CSMA/CD, TCP/IP
|
| Installed SFP modules quantity |
0
|
| 10G support |
No
|
| MAC address table |
8000 entries
|
| Switch type |
Unmanaged
|
| Fanless |
Yes
|
| Basic switching RJ-45 Ethernet ports quantity |
Fast Ethernet (10/100)
|
| Packet buffer memory |
2 MB
|
| Store-and-forward |
Yes
|
| Power connector |
AC-in jack
|
| Networking standards |
IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
|
| Cable types supported |
Cat3, Cat5e, Cat4, Cat5
|
| Fast Ethernet (copper) ports quantity |
24
|
| Copper ethernet cabling technology |
10GBASE-T, 100BASE-TX
|
| Switching capacity |
4.8 Gbit/s
|
| Throughput |
3.57 Mpps
|
| Forwarding rate |
3.57 Mpps
|
| Heat dissipation |
10.88 BTU/h
|
| Porturi RJ 45 |
24-28
|
| Viteza Transfer |
Fast Ethernet
|
| Porturi SFP |
N/A
|
| Montare in Rack |
Nu
|
| Management |
Nu
|
| PoE |
Nu
|
| Operating temperature (T-T) |
0 – 40 °C
|
| Cables included |
AC
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Harmonized System (HS) code |
85176990
|
| Depth |
180 mm
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| Sustainability compliance |
Yes
|
| LED indicators |
Yes
|
| Housing material |
Metal
|
| Package type |
Box
|
| Power source |
AC
|
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS
|
| Package height |
80 mm
|
| Package weight |
2 kg
|
| Package width |
250 mm
|
| Package depth |
400 mm
|
| Width |
294 mm
|
| Power consumption (typical) |
3.53 W
|
| Producator |
TP-LINK
|
| Garantie |
36
|
|
