| LAN-Port-Type |
FastEthernet
|
| Stackable |
No
|
| Storage relative humidity (H-H) |
5 – 90%
|
| Power supply included |
Yes
|
| Full duplex |
Yes
|
| Rack mounting |
Yes
|
| Ethernet LAN data rates |
10,100 Mbit/s
|
| Power connector |
DC-in jack
|
| Power over Ethernet (PoE) |
No
|
| Auto MDI/MDI-X |
Yes
|
| Flow control support |
Yes
|
| DC input voltage |
9 V
|
| Auto-negotiation |
Yes
|
| Input current |
0.6 A
|
| Installed SFP modules quantity |
0
|
| 10G support |
No
|
| Half duplex |
Yes
|
| Switch type |
Unmanaged
|
| Fanless |
Yes
|
| Basic switching RJ-45 Ethernet ports quantity |
Fast Ethernet (10/100)
|
| MAC address table |
2000 entries
|
| Store-and-forward |
Yes
|
| MAC address auto-learning supported |
Yes
|
| Copper ethernet cabling technology |
100BASE-TX, 10BASE-T
|
| Fast Ethernet (copper) ports quantity |
16
|
| Switching capacity |
3.2 Gbit/s
|
| Networking standards |
IEEE 802.3u, IEEE 802.3x
|
| Minimum system requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7, MAC OS, NetWare, UNIX, Linux
|
| Heat dissipation |
11.01 BTU/h
|
| Porturi RJ 45 |
11-18
|
| Viteza Transfer |
Fast Ethernet
|
| Porturi SFP |
N/A
|
| Montare in Rack |
Nu
|
| Management |
Nu
|
| PoE |
Nu
|
| Operating temperature (T-T) |
0 – 40 °C
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Height |
40 mm
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| Sustainability compliance |
Yes
|
| LED indicators |
Yes
|
| Package type |
Box
|
| Package height |
68 mm
|
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS
|
| Package weight |
590 g
|
| Wall mountable |
Yes
|
| Power source |
DC
|
| Width |
200 mm
|
| Package width |
223 mm
|
| Depth |
142 mm
|
| Package depth |
285 mm
|
| Power consumption (max) |
3.23 W
|
| Producator |
TP-LINK
|
| Garantie |
36
|
|
