| LAN-Port-Type |
FastEthernet
|
| Storage relative humidity (H-H) |
5 – 90%
|
| Full duplex |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Web-based management |
Yes
|
| Switch type |
Managed
|
| Ethernet LAN data rates |
10,100 Mbit/s
|
| Fast Ethernet (copper) ports quantity |
5
|
| Power connector |
DC-in jack
|
| Power over Ethernet (PoE) |
No
|
| Rack mounting |
No
|
| Auto MDI/MDI-X |
Yes
|
| Flow control support |
Yes
|
| Auto-negotiation |
Yes
|
| Input current |
0.6 A
|
| Power supply included |
No
|
| Supported network protocols |
CSMA/CD, TCP/IP
|
| DC input voltage |
5 V
|
| Installed SFP modules quantity |
0
|
| 10G support |
No
|
| Spanning tree protocol |
Yes
|
| Fanless |
Yes
|
| Basic switching RJ-45 Ethernet ports quantity |
Fast Ethernet (10/100)
|
| Store-and-forward |
Yes
|
| MAC address table |
1000 entries
|
| Switching capacity |
1.6 Gbit/s
|
| Copper ethernet cabling technology |
10BASE-T, 100BASE-T
|
| Networking standards |
IEEE 802.3u, IEEE 802.3x
|
| Heat dissipation |
6.38 BTU/h
|
| Porturi RJ 45 |
5-10
|
| Viteza Transfer |
Fast Ethernet
|
| Porturi SFP |
N/A
|
| Montare in Rack |
Nu
|
| Management |
Nu
|
| PoE |
Nu
|
| Operating temperature (T-T) |
0 – 40 °C
|
| Cables included |
AC
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Product colour |
White
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| Sustainability compliance |
Yes
|
| LED indicators |
Yes
|
| Package type |
Box
|
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS
|
| Package height |
85 mm
|
| AC input frequency |
50 Hz
|
| Power source |
DC
|
| AC input voltage |
220 V
|
| Power consumption (typical) |
1.87 W
|
| Power consumption (max) |
1.87 W
|
| Width |
103.5 mm
|
| Depth |
70 mm
|
| Package width |
91 mm
|
| Package depth |
108 mm
|
| Package weight |
190 g
|
| Certification |
FCC, RoHS
|
| Height |
22 mm
|
| Producator |
TP-LINK
|
| Garantie |
36
|
|
