| LAN-Port-Type |
Gigabit
|
| Storage relative humidity (H-H) |
5 – 95%
|
| Jumbo frames support |
Yes
|
| Power supply included |
Yes
|
| Ethernet LAN data rates |
10,100,1000 Mbit/s
|
| Pallet gross width |
120 cm
|
| Input current |
1.5 A
|
| Number of fans |
0 fan(s)
|
| Input voltage |
12 V
|
| Pallet gross length |
110 cm
|
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
|
| Full duplex |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Form factor |
1U
|
| Power connector |
DC-in jack
|
| Power over Ethernet (PoE) |
No
|
| Rack mounting |
No
|
| Switch layer |
L2
|
| Auto MDI/MDI-X |
Yes
|
| Flow control support |
Yes
|
| Number of power supply units |
1
|
| Auto-negotiation |
Yes
|
| Redundant power supply (RPS) support |
No
|
| Installed SFP modules quantity |
0
|
| Basic switching RJ-45 Ethernet ports quantity |
24
|
| Gigabit Ethernet (copper) ports quantity |
24
|
| 10G support |
No
|
| Half duplex |
Yes
|
| Number of queues |
8
|
| MAC address table |
8000 entries
|
| Switch type |
Unmanaged
|
| Jumbo frames |
9216
|
| Packet buffer memory |
2 MB
|
| Store-and-forward |
Yes
|
| Copper ethernet cabling technology |
1000BASE-T, 100BASE-TX, 10BASE-T
|
| Switching capacity |
48 Gbit/s
|
| Forwarding rate |
35.71 Mpps
|
| Shipping (inner) case height |
27 cm
|
| Shipping (inner) case width |
41.3 cm
|
| Shipping (inner) case length |
46.3 cm
|
| Shipping (inner) case net weight |
11.5 kg
|
| Pallet gross weight (air) |
373.6 kg
|
| Products per pallet (air) |
140 pc(s)
|
| Pallet height (air) |
2.02 m
|
| Pallet gross weight (sea) |
373.6 kg
|
| Master (outer) cases per pallet (air) |
28 pc(s)
|
| Products per pallet (sea) |
140 pc(s)
|
| Pallet height (sea) |
2.02 m
|
| Shipping (inner) case gross weight |
12.4 kg
|
| Porturi RJ 45 |
24-28
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
N/A
|
| Montare in Rack |
Nu
|
| Management |
Nu
|
| PoE |
Nu
|
| Operating temperature (T-T) |
0 – 40 °C
|
| Storage temperature (T-T) |
-10 – 70 °C
|
| Operating relative humidity (H-H) |
5 – 90%
|
| Housing material |
Plastic
|
| Height |
46 mm
|
| Power consumption (typical) |
15.7 W
|
| LED indicators |
Activity, Link
|
| Depth |
178 mm
|
| Weight |
760 g
|
| Mean time between failures (MTBF) |
336072 h
|
| Heat dissipation |
53.58 BTU/h
|
| Width |
257 mm
|
| Certification |
RoHS, FCC, CE, C-Tick, CB, cUL
|
| Producator |
D-LINK
|
| Garantie |
24
|
|
