| LAN-Port-Type |
Gigabit
|
| Storage relative humidity (H-H) |
5 – 95%
|
| Jumbo frames support |
Yes
|
| Power supply included |
Yes
|
| Ethernet LAN data rates |
10,100,1000 Mbit/s
|
| Pallet gross width |
120 cm
|
| Input current |
1 A
|
| Number of fans |
0 fan(s)
|
| Pallet gross length |
110 cm
|
| Full duplex |
Yes
|
| Rack mounting |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Form factor |
1U
|
| Power connector |
DC-in jack
|
| Power over Ethernet (PoE) |
No
|
| Switch layer |
L2
|
| Auto MDI/MDI-X |
Yes
|
| Flow control support |
Yes
|
| Products per pallet (air) |
300 pc(s)
|
| Pallet height (sea) |
2.06 m
|
| Number of power supply units |
1
|
| DC input voltage |
12 V
|
| Auto-negotiation |
Yes
|
| Redundant power supply (RPS) support |
No
|
| Installed SFP modules quantity |
0
|
| 10G support |
No
|
| Half duplex |
Yes
|
| Number of queues |
8
|
| Basic switching RJ-45 Ethernet ports quantity |
16
|
| MAC address table |
8000 entries
|
| Switch type |
Unmanaged
|
| Switching capacity |
32 Gbit/s
|
| Jumbo frames |
9216
|
| Gigabit Ethernet (copper) ports quantity |
16
|
| Store-and-forward |
Yes
|
| Copper ethernet cabling technology |
1000BASE-T, 100BASE-TX, 10BASE-T
|
| Networking standards |
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
|
| Packet buffer memory |
0.512 MB
|
| Shipping (inner) case gross weight |
15.6 kg
|
| Forwarding rate |
23.81 Mpps
|
| Master (outer) cases per pallet (air) |
30 pc(s)
|
| Pallet height (air) |
2.06 m
|
| Shipping (inner) case height |
38.4 cm
|
| Mean time between failures (MTBF) |
305171 h
|
| Heat dissipation |
39.92 BTU/h
|
| Shipping (inner) case width |
34 cm
|
| Shipping (inner) case length |
56.9 cm
|
| Shipping (inner) case net weight |
15 kg
|
| Pallet gross weight (air) |
491.5 kg
|
| Pallet gross weight (sea) |
491.5 kg
|
| Products per pallet (sea) |
300 pc(s)
|
| Porturi RJ 45 |
11-18
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
N/A
|
| Montare in Rack |
Nu
|
| Management |
Nu
|
| PoE |
Nu
|
| Operating temperature (T-T) |
0 – 40 °C
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Harmonized System (HS) code |
85176990
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| LED indicators |
Yes
|
| Housing material |
Metal
|
| Width |
280 mm
|
| Package width |
180 mm
|
| Products per shipping (inner) case |
10 pc(s)
|
| Weight |
870 g
|
| Package weight |
1.45 kg
|
| Depth |
126 mm
|
| Package height |
108 mm
|
| Package depth |
328 mm
|
| Power consumption (max) |
11.7 W
|
| Certification |
CE Class A, FCC Class A, VCCI Class A, BSMI, CCC UL, CB, LVD, BSMI, CCC
|
| Producator |
D-LINK
|
| Garantie |
24
|
|
