| LAN-Port-Type |
Gigabit
|
| Jumbo frames support |
Yes
|
| Link aggregation |
Yes
|
| Power supply included |
Yes
|
| Storage relative humidity (H-H) |
0 – 95%
|
| Pallet gross width |
120 cm
|
| Pallet gross length |
110 cm
|
| Full duplex |
Yes
|
| Rack mounting |
Yes
|
| VLAN support |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Static route |
Yes
|
| Web-based management |
Yes
|
| System event log |
Yes
|
| Switch type |
Managed
|
| 10G support |
Yes
|
| Port mirroring |
Yes
|
| Firmware upgradeable |
Yes
|
| Access Control List (ACL) |
Yes
|
| Internal memory |
2048 MB
|
| Power over Ethernet (PoE) |
No
|
| Auto MDI/MDI-X |
Yes
|
| Flow control support |
Yes
|
| IGMP snooping |
Yes
|
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T
|
| Installed SFP modules quantity |
0
|
| Master (outer) cases per pallet (air) |
24 pc(s)
|
| Configuring Location Settings (CLI) |
Yes
|
| Basic switching RJ-45 Ethernet ports quantity |
24
|
| Console port |
RJ-45
|
| Broadcast storm control |
Yes
|
| Spanning tree protocol |
Yes
|
| Multicast support |
Yes
|
| Switch layer |
L3
|
| MAC address table |
16000 entries
|
| Switching capacity |
128 Gbit/s
|
| Loop protection |
Yes
|
| Memory type |
DDR3-SDRAM
|
| ARP inspection |
Yes
|
| Flash memory |
64 MB
|
| Virtual LAN features |
Voice VLAN
|
| Store-and-forward |
Yes
|
| Packet buffer memory |
12 MB
|
| Head-of-line (HOL) blocking |
Yes
|
| Number of VLANs |
4094
|
| Queue scheduling algorithms |
Weighted Round Robin (WRR)
|
| IP-MAC-Port binding |
Yes
|
| Cable types supported |
Cat5, Cat5e
|
| Jumbo frames |
12000
|
| Pallet height (sea) |
2.04 m
|
| Products per pallet (sea) |
120 pc(s)
|
| Forwarding rate |
95.24 Mpps
|
| Fiber ethernet cabling technology |
100BASE-FX, 1000BASE-LHX, 1000BASE-X, 1000BASE‑LX, 1000BASE‑SX, 1000BASE‑ZX
|
| Number of static routes |
124
|
| Access Control List (ACL) rules |
768
|
| Electromagnetic compatibility |
CE A, VCCI A, FCC A, IC, BSMI
|
| Shipping (inner) case width |
47.8 cm
|
| Shipping (inner) case length |
58.5 cm
|
| Pallet height (air) |
2.04 m
|
| DHCP features |
DHCP client, DHCP server, DHCP snooping
|
| Security algorithms |
EAP, MD5, PEAP, SSH, SSL/TLS, TTLS
|
| Mean time between failures (MTBF) |
743482.45 h
|
| Heat dissipation |
104.346 BTU/h
|
| Shipping (inner) case height |
31.8 cm
|
| Shipping (inner) case net weight |
11.6 kg
|
| Pallet gross weight (air) |
407.6 kg
|
| Products per pallet (air) |
120 pc(s)
|
| Pallet gross weight (sea) |
407.6 kg
|
| Shipping (inner) case gross weight |
16.2 kg
|
| Porturi RJ 45 |
24-28
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
3-4
|
| Montare in Rack |
Nu
|
| SFP module slots quantity |
4
|
| Management |
Da
|
| PoE |
Nu
|
| Harmonized System (HS) code |
85176990
|
| Operating relative humidity (H-H) |
0 – 95%
|
| Storage temperature (T-T) |
-20 – 70 °C
|
| Package weight |
2.97 kg
|
| Depth |
140 mm
|
| Weight |
3.86 kg
|
| LED indicators |
Activity, Link, Power, Speed
|
| Products per shipping (inner) case |
5 pc(s)
|
| Certification |
CB, UL, BSMI, CCC
|
| Package height |
89 mm
|
| Package depth |
563 mm
|
| Noise level |
47.6 dB
|
| Power consumption (max) |
30.6 W
|
| Package width |
282 mm
|
| Producator |
D-LINK
|
| Garantie |
60
|
|
