| LAN-Port-Type |
Gigabit
|
| Jumbo frames support |
Yes
|
| Link aggregation |
Yes
|
| Power supply included |
Yes
|
| Ethernet LAN data rates |
10,100,1000 Mbit/s
|
| Storage relative humidity (H-H) |
0 – 95%
|
| Power over Ethernet (PoE) |
Yes
|
| Full duplex |
Yes
|
| VLAN support |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Web-based management |
Yes
|
| Switch type |
Managed
|
| Port mirroring |
Yes
|
| Rack mounting |
No
|
| Basic switching RJ-45 Ethernet ports quantity |
8
|
| Auto MDI/MDI-X |
Yes
|
| Flow control support |
Yes
|
| IGMP snooping |
Yes
|
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T
|
| Installed SFP modules quantity |
0
|
| Flash memory |
2 MB
|
| 10G support |
No
|
| Half duplex |
Yes
|
| Broadcast storm control |
Yes
|
| Multicast support |
Yes
|
| Jumbo frames |
9216
|
| Fanless |
Yes
|
| Loop protection |
Yes
|
| Number of queues |
4
|
| Power over Ethernet plus (PoE+) ports quantity |
8
|
| MAC address table |
4096 entries
|
| Power over Ethernet (PoE) power per port |
30 W
|
| Gigabit Ethernet (copper) ports quantity |
8
|
| Switching capacity |
16 Gbit/s
|
| Forwarding rate |
11.9 Mpps
|
| Number of VLANs |
4094
|
| Total Power over Ethernet (PoE) budget |
64 W
|
| Virtual LAN features |
Port-based VLAN, Tagged VLAN, Voice VLAN
|
| Queue scheduling algorithms |
SP, Weighted Round Robin (WRR)
|
| Mean time between failures (MTBF) |
786841 h
|
| Heat dissipation |
265.85 BTU/h
|
| Porturi RJ 45 |
5-10
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
N/A
|
| Montare in Rack |
Da
|
| Management |
Da
|
| PoE |
Da
|
| Operating temperature (T-T) |
0 – 40 °C
|
| Weight |
430 g
|
| Operating relative humidity (H-H) |
0 – 90%
|
| Depth |
97.8 mm
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| Sustainability compliance |
Yes
|
| LED indicators |
Yes
|
| Compliance certificates |
CE, RoHS
|
| Width |
171 mm
|
| Height |
28.6 mm
|
| Power consumption (max) |
77.9 W
|
| Certification |
FCC Class B, CE Class B, VCCI Class B, BSMI cUL, CE LVD, CB, BSMI
|
| Producator |
D-LINK
|
| Garantie |
60
|
|
