| LAN-Port-Type |
Gigabit
|
| Storage relative humidity (H-H) |
5 – 95%
|
| Jumbo frames support |
Yes
|
| Full duplex |
Yes
|
| Rack mounting |
Yes
|
| Web-based management |
Yes
|
| Form factor |
1U
|
| Power over Ethernet (PoE) |
No
|
| Basic switching RJ-45 Ethernet ports quantity |
8
|
| Flow control support |
Yes
|
| Auto-negotiation |
Yes
|
| Installed SFP modules quantity |
0
|
| Console port |
RJ-45
|
| 10G support |
No
|
| Broadcast storm control |
Yes
|
| Switch type |
Unmanaged
|
| Jumbo frames |
9216
|
| Loop protection |
Yes
|
| BPDU filtering/protection |
Yes
|
| Gigabit Ethernet (copper) ports quantity |
8
|
| Switching capacity |
16 Gbit/s
|
| MAC address table |
4000 entries
|
| Copper ethernet cabling technology |
10BASE-T, 100BASE-T, 1000BASE-T
|
| Packet forwarding rate (100 Mbps) |
148800 pps
|
| Packet forwarding rate (10 Mbps) |
14880 pps
|
| Throughput |
11.9 Mpps
|
| Buffer size |
128 KB
|
| Networking standards |
IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
|
| Packet forwarding rate (1 Gbps) |
1488000 pps
|
| Safety |
UL60950-1, 2nd Edition, CSA C22.2 No.60950-1-07, 2nd Edition, IEC60950-1(UL-EU, UL-CB)
|
| Input current |
0.2 A
|
| Included power plug types |
UK
|
| Porturi RJ 45 |
5-10
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
N/A
|
| Montare in Rack |
Da
|
| Management |
Nu
|
| PoE |
Nu
|
| Operating relative humidity (H-H) |
5 – 90%
|
| Width |
210 mm
|
| Height |
38 mm
|
| Operating temperature (T-T) |
0 – 50 °C
|
| LED indicators |
Yes
|
| Housing material |
Metal
|
| Wall mountable |
Yes
|
| Power consumption (max) |
4.5 W
|
| Depth |
121 mm
|
| Weight |
780 g
|
| Storage temperature (T-T) |
-25 – 70 °C
|
| Certification |
EAC certification, EN55024, ICES Class A, VCCI Class A, FCC Class A, RCM, CE, EN55022, CISPR 55022
|
| Producator |
ALLIED TELESIS
|
| Garantie |
24
|
|
