Name: Placa de bază MSI B550-A PRO AM4 - A.W.P.S Store
Brand: MSI
SKU: B550-A PRO
Price: 585.23 RON
Availability: OutOfStock

Placa de bază MSI B550-A PRO AM4

Adăugați preferateAdăugat la lista de preferințeEliminat din lista de dorințe 0

Seria PRO ajuta utilizatorii sa lucreze mai inteligent, oferind o experienta eficienta si productiva. Dispunand de functionalitate stabila si de asamblare de inalta calitate, placile de baza din seria PRO asigura nu numai fluxuri de lucru profesionale optimizate, dar si mai putina depanare si longevitate ridicata.

Specificație: Placa de bază MSI B550-A PRO AM4

PCI	0
Serial-or-Paralel	No/No
Video-Connection	HDMI/DP
Wi-FI	No
CPU încorporat	No
Component for	PC
Ethernet interface type	Gigabit Ethernet
Memory channels	Dual-channel
Ethernet LAN	Yes
HDMI ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	1
Maximum internal memory	128 GB
Processor manufacturer	AMD
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 2.0 ports quantity	4
PCI Express x1 (Gen 3.x) slots	2
PCI Express x16 (Gen 3.x) slots	1
Audio output channels	7.1 channels
PCI Express x16 (Gen 4.x) slots	1
On-board graphics card	No
Supported storage drive types	HDD & SSD
Supported memory types	DDR4-SDRAM
Number of M.2 (M) slots	2
Processor socket	Socket AM4
Motherboard chipset	AMD B550
DisplayPorts quantity	1
VGA (D-Sub) ports quantity	0
DVI-D ports quantity	0
Maximum resolution	4096 x 2160 pixels
Drivers included	Yes
Model Chipset	B550
Gaming	Da
Format:	ATX
Soclu Procesor	Socket AM4
Tip Memorie	DDR4
Numar sloturi memorie	4
Memorie maxima	128 GB
Tip slot interfata grafica	N/A
Chipset audio integrat	Realtek
Canale audio	7.1
Wireless	Nu
Bluetooth	Nu
USB Type-C	Da
HDMI	Nu
Thunderbolt	Nu
Sloturi M.2	2
RJ-45 LAN	1
Compatible processor series	AMD Ryzen 3000 Series
Number of memory slots	4
Memory slots type	DIMM
USB 2.0 connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Number of SATA II connectors	0
Number of SATA connectors	0
Number of Parallel ATA connectors	0
Front panel audio connector	Yes
ATX Power connector (24-pin)	Yes
CPU fan connector	Yes
PS/2 ports quantity	1
Motherboard chipset family	AMD
Clear CMOS jumper	Yes
mSATA ports quantity	0
ECC сompatibility	ECC & Non-ECC
TPM connector	Yes
RGB LED pin header	Yes
Motherboard form factor	ATX
Maximum number of SMP processors	1
12V power connector	Yes
Supported storage drive interfaces	SATA III
RAID levels	0, 1, 10
Parallel processing technology support	2-Way CrossFireX
Maximum graphics card memory	16000 MB
Number of SATA III connectors	6
Number of chassis fan connectors	6
Chassis intrusion connector	Yes
eSATA ports quantity	0
Firewire (IEEE 1394) ports	0
LAN controller	Realtek 8111H
Audio Chip	Realtek ALC892
Number of mounting holes	9
Supported memory clock speeds	1866,2133,2400,2667,2800,2933,3000,3066,3200,3466,3600,3733,3866,4000,4133,4266,4400,4800 MHz
Harmonized System (HS) code	84733020
Cables included	SATA
Width	305 mm
Depth	244 mm
Height	65 mm
Weight	1 kg
Producator	MSI
Garantie	36
