| Canal Ethernet |
Da
|
| HDMI version |
2.0
|
| Colour depth |
8 bit
|
| Data transfer rate |
18 Gbit/s
|
| Maximum resolution |
4096 x 2160 pixels
|
| Cable type |
Round cable
|
| Cable jacket material |
Polyvinyl chloride (PVC)
|
| Connector contacts plating |
Gold
|
| Connector 2 |
HDMI Type A (Standard)
|
| Connector 1 gender |
Male
|
| Connector 2 gender |
Male
|
| Connector 1 form factor |
Straight
|
| Connector 2 form factor |
Straight
|
| Conector 1: |
HDMI
|
| Conector 2: |
HDMI
|
| Lungime Cablu |
1.6m – 2m
|
| Connector 1 |
HDMI Type A (Standard)
|
| AWG wire size |
30
|
| Supported graphics resolutions |
4096 x 2160
|
| Connector housing material |
Acrylonitrile butadiene styrene (ABS)
|
| Connector material |
Gold
|
| HDMI Ethernet channel |
Yes
|
| Cable material |
Tinned copper
|
| Contact material |
Phosphor copper
|
| Shield material |
Copper
|
| Bending radius (min) |
6 cm
|
| Nominal attenuation |
300kHz-825MHz 5dB, 825MHz-2.475GHz 5dB,2.475GHz-4.125GHz 12dB, 4.125GHz-5.1GHz 20dB
|
| Cable diameter |
6 mm
|
| Connector 1 dimensions (WxDxH) |
20 x 34.1 x 11.8 mm
|
| Connector 2 dimensions (WxDxH) |
20 x 34.1 x 11.8 mm
|
| Product colour |
Grey, Silver
|
| Harmonized System (HS) code |
84733080
|
| Cable length |
2 m
|
| Package type |
Polybag
|
| Operating temperature (T-T) |
-10 – 80 °C
|
| Colour sampling |
4:4:4
|
| Certification |
RoHS, REACH, UL, ATC
|
| Producator |
LINDY
|
| Garantie |
24
|
|
