| LAN-Port-Type |
Gigabit
|
| Storage relative humidity (H-H) |
5 – 90%
|
| Plug and Play |
Yes
|
| Jumbo frames support |
Yes
|
| Link aggregation |
Yes
|
| Power supply included |
Yes
|
| Input current |
1 A
|
| Input voltage |
12 V
|
| Full duplex |
Yes
|
| VLAN support |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Port mirroring |
Yes
|
| Power over Ethernet (PoE) |
No
|
| Rack mounting |
No
|
| Switch layer |
L2
|
| Auto MDI/MDI-X |
Yes
|
| Rate limiting |
Yes
|
| IGMP snooping |
Yes
|
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T
|
| Auto-negotiation |
Yes
|
| Installed SFP modules quantity |
0
|
| 10G support |
No
|
| Broadcast storm control |
Yes
|
| Basic switching RJ-45 Ethernet ports quantity |
16
|
| MAC address table |
8000 entries
|
| Switch type |
Unmanaged
|
| Cable types supported |
Cat3, Cat4, Cat5, Cat5e, Cat6
|
| Switching capacity |
32 Gbit/s
|
| Loop protection |
Yes
|
| Number of queues |
4
|
| Packet buffer memory |
4.1 MB
|
| Gigabit Ethernet (copper) ports quantity |
16
|
| Store-and-forward |
Yes
|
| Number of VLANs |
32
|
| Jumbo frames |
10000
|
| Rubber feet |
Yes
|
| Cable length detection |
Yes
|
| Networking standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
|
| Virtual LAN features |
Tagged VLAN, Protocol-based VLAN
|
| Forwarding rate |
23.81 Mpps
|
| Heat dissipation |
31.68 BTU/h
|
| Porturi RJ 45 |
11-18
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
N/A
|
| Montare in Rack |
Nu
|
| Management |
Nu
|
| PoE |
Nu
|
| Operating temperature (T-T) |
0 – 40 °C
|
| Quick start guide |
Yes
|
| Cables included |
AC
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Harmonized System (HS) code |
85176990
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| LED indicators |
Yes
|
| Housing material |
Metal
|
| Height |
25.4 mm
|
| Package width |
170 mm
|
| Package height |
70 mm
|
| Power source |
DC
|
| Certification |
FCC, CE, RoHS
|
| Package weight |
1.36 kg
|
| Package depth |
412 mm
|
| Power consumption (max) |
9.19 W
|
| Width |
286 mm
|
| Depth |
111.7 mm
|
| Producator |
TP-LINK
|
| Garantie |
60
|
|
