| LAN-Port-Type |
Gigabit
|
| Storage relative humidity (H-H) |
5 – 90%
|
| Connectivity technology |
Wired
|
| Jumbo frames support |
Yes
|
| Power supply included |
Yes
|
| Full duplex |
Yes
|
| Rack mounting |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Form factor |
1U
|
| Auto MDI/MDI-X |
Yes
|
| Flow control support |
Yes
|
| Auto-negotiation |
Yes
|
| Rack mount kit |
Yes
|
| Supported network protocols |
CSMA/CD, TCP/IP
|
| Supported data transfer rates |
10/100/1000 Mbps
|
| Installed SFP modules quantity |
0
|
| Basic switching RJ-45 Ethernet ports quantity |
24
|
| Gigabit Ethernet (copper) ports quantity |
24
|
| 10G support |
No
|
| Half duplex |
Yes
|
| MAC address table |
8000 entries
|
| Switch type |
Unmanaged
|
| Store-and-forward |
Yes
|
| Copper ethernet cabling technology |
1000BASE-T, 100BASE-TX, 10BASE-T
|
| Maximum data transfer rate (2.4 GHz) |
1 Gbit/s
|
| Connectivity LEDs |
Y
|
| Switching capacity |
48 Gbit/s
|
| Jumbo frames |
10000
|
| Forwarding rate |
35.7 Mpps
|
| Networking standards |
IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
|
| Bandwidth |
48 Gbit/s
|
| Dimensions (W x D x H) (imperial) |
439.4 x 180.3 x 43.2 mm (17.3 x 7.1 x 1.7)
|
| Heat dissipation |
46.44 BTU/h
|
| Porturi RJ 45 |
24-28
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
N/A
|
| Montare in Rack |
Nu
|
| Management |
Nu
|
| PoE |
Nu
|
| Cables included |
AC
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Depth |
180 mm
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| Power source |
AC
|
| Operating temperature (T-T) |
32 – 104 °F
|
| Certification |
FCC, CE, RoHS
|
| Package width |
250 mm
|
| Package weight |
2.13 kg
|
| Package depth |
528 mm
|
| Power consumption (max) |
13.62 W
|
| Producator |
TP-LINK
|
| Garantie |
60
|
|
