| LAN-Port-Type |
FastEthernet
|
| Storage relative humidity (H-H) |
5 – 90%
|
| Jumbo frames support |
Yes
|
| Power supply included |
Yes
|
| Power over Ethernet (PoE) |
Yes
|
| Full duplex |
Yes
|
| Rack mounting |
No
|
| Auto MDI/MDI-X |
Yes
|
| Flow control support |
Yes
|
| Auto-negotiation |
Yes
|
| Installed SFP modules quantity |
0
|
| 10G support |
No
|
| Half duplex |
Yes
|
| Switch type |
Unmanaged
|
| Fanless |
Yes
|
| Basic switching RJ-45 Ethernet ports quantity |
Fast Ethernet (10/100)
|
| MAC address table |
2000 entries
|
| Switching capacity |
1 Gbit/s
|
| Power over Ethernet (PoE) ports quantity |
4
|
| Cable types supported |
Cat3, Cat4, Cat5, Cat5e
|
| MAC address auto-aging supported |
Yes
|
| Store-and-forward |
Yes
|
| Input current |
0.81 A
|
| Jumbo frames |
2000
|
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX
|
| Input voltage |
53.5 V
|
| Forwarding rate |
0.744 Mpps
|
| Networking standards |
IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
|
| Total Power over Ethernet (PoE) budget |
41 W
|
| Heat dissipation |
160.27 BTU/h
|
| Porturi RJ 45 |
5-10
|
| Viteza Transfer |
Fast Ethernet
|
| Porturi SFP |
N/A
|
| Montare in Rack |
Nu
|
| Management |
Nu
|
| PoE |
Da
|
| Operating temperature (T-T) |
0 – 40 °C
|
| Operating relative humidity (H-H) |
10 – 90%
|
| Harmonized System (HS) code |
85176990
|
| Depth |
98 mm
|
| Width |
100 mm
|
| Storage temperature (T-T) |
-40 – 70 °C
|
| Sustainability compliance |
Yes
|
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS
|
| Height |
25 mm
|
| Package weight |
740 g
|
| AC input frequency |
50 Hz
|
| AC input voltage |
220 V
|
| Power source |
DC/PoE
|
| Package depth |
196 mm
|
| Package width |
131 mm
|
| Package height |
121 mm
|
| Power consumption (max) |
47 W
|
| Producator |
TP-LINK
|
| Garantie |
60
|
|
