| LAN-Port-Type |
Gigabit
|
| Stackable |
Yes
|
| Jumbo frames support |
Yes
|
| Link aggregation |
Yes
|
| Power supply included |
Yes
|
| Storage relative humidity (H-H) |
0 – 95%
|
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
|
| Full duplex |
Yes
|
| Rack mounting |
Yes
|
| VLAN support |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Web-based management |
Yes
|
| System event log |
Yes
|
| Switch type |
Managed
|
| Port mirroring |
Yes
|
| Form factor |
1U
|
| MAC address filtering |
Yes
|
| Access Control List (ACL) |
Yes
|
| Internal memory |
256 MB
|
| Power over Ethernet (PoE) |
No
|
| Switch layer |
L2
|
| Auto MDI/MDI-X |
Yes
|
| Flow control support |
Yes
|
| IGMP snooping |
Yes
|
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T
|
| Auto-negotiation |
Yes
|
| Installed SFP modules quantity |
0
|
| Configuring Location Settings (CLI) |
Yes
|
| Broadcast storm control |
Yes
|
| Spanning tree protocol |
Yes
|
| Multicast support |
Yes
|
| Basic switching RJ-45 Ethernet ports quantity |
16
|
| MAC address table |
8000 entries
|
| Loop protection |
Yes
|
| Flash memory |
32 MB
|
| Memory type |
DDR3-SDRAM
|
| ARP inspection |
Yes
|
| MIB support |
Y
|
| Packet buffer memory |
4.1 MB
|
| Store-and-forward |
Yes
|
| Power connector |
AC-in jack
|
| Combo SFP ports quantity |
4
|
| Head-of-line (HOL) blocking |
Yes
|
| Number of VLANs |
256
|
| Jumbo frames |
10000
|
| Forwarding rate |
77.4 Mpps
|
| DHCP features |
DHCP server, DHCP client
|
| Switching capacity |
40 Gbit/s
|
| Mean time between failures (MTBF) |
1087100 h
|
| Porturi RJ 45 |
11-18
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
3-4
|
| Montare in Rack |
Da
|
| Management |
Da
|
| PoE |
Nu
|
| Product colour |
Black
|
| Depth |
180 mm
|
| Operating relative humidity (H-H) |
0 – 95%
|
| Operating temperature (T-T) |
5 – 50 °C
|
| LED indicators |
Yes
|
| Width |
280 mm
|
| Power source |
AC
|
| Storage temperature (T-T) |
-20 – 70 °C
|
| AC input frequency |
50/60 Hz
|
| Height |
44 mm
|
| Noise level |
0 dB
|
| Weight |
1.75 kg
|
| Power consumption (max) |
13.08 W
|
| Heat dissipation |
44.62 BTU/h
|
| Producator |
D-LINK
|
| Garantie |
60
|
|
