| LAN-Port-Type |
Gigabit
|
| Stackable |
Yes
|
| Jumbo frames support |
Yes
|
| Storage relative humidity (H-H) |
0 – 95%
|
| Pallet gross width |
120 cm
|
| Cable management |
Yes
|
| Power over Ethernet (PoE) |
Yes
|
| Pallet gross length |
110 cm
|
| Full duplex |
Yes
|
| Rack mounting |
Yes
|
| VLAN support |
Yes
|
| Quality of Service (QoS) support |
Yes
|
| Switch type |
Managed
|
| 10G support |
Yes
|
| MAC address filtering |
Yes
|
| Access Control List (ACL) |
Yes
|
| Switch layer |
L2
|
| Basic switching RJ-45 Ethernet ports quantity |
8
|
| Flow control support |
Yes
|
| IGMP snooping |
Yes
|
| Master (outer) cases per pallet (air) |
54 pc(s)
|
| Products per pallet (sea) |
270 pc(s)
|
| Installed SFP modules quantity |
0
|
| Spanning tree protocol |
Yes
|
| Multicast support |
Yes
|
| MAC address table |
16000 entries
|
| SSH/SSL support |
Yes
|
| Switching capacity |
20 Gbit/s
|
| Power over Ethernet plus (PoE+) ports quantity |
8
|
| Head-of-line (HOL) blocking |
Yes
|
| Static port security |
Yes
|
| DHCP features |
DHCP server, DHCP client
|
| Shipping (inner) case height |
31.7 cm
|
| Shipping (inner) case width |
34.6 cm
|
| Shipping (inner) case length |
38.2 cm
|
| Products per pallet (air) |
180 pc(s)
|
| Pallet height (air) |
140.3 cm
|
| Pallet height (sea) |
2.04 m
|
| Safety |
cUL, LVD
|
| Networking standards |
IEEE 802.1D, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3af
|
| Packet buffer memory |
6 MB
|
| Management protocols |
SNMP, RMON
|
| Data link protocols |
IP
|
| Packet transfer speed |
14.9 Mp/s
|
| Shipping (inner) case net weight |
10.8 kg
|
| Pallet gross weight (air) |
436.1 kg
|
| Pallet gross weight (sea) |
644.9 kg
|
| Shipping (inner) case gross weight |
11.6 kg
|
| Porturi RJ 45 |
5-10
|
| Viteza Transfer |
Gigabit
|
| Porturi SFP |
1-2
|
| Montare in Rack |
Da
|
| SFP module slots quantity |
2
|
| Management |
Da
|
| PoE |
Da
|
| Harmonized System (HS) code |
85176990
|
| Depth |
180 mm
|
| Operating relative humidity (H-H) |
0 – 95%
|
| LED indicators |
Yes
|
| Width |
280 mm
|
| Storage temperature (T-T) |
-20 – 70 °C
|
| Package weight |
2.17 kg
|
| Package depth |
331 mm
|
| Package height |
72 mm
|
| Power LED |
Yes
|
| Products per shipping (inner) case |
5 pc(s)
|
| Package width |
288 mm
|
| Certification |
CE Class A
|
| Producator |
D-LINK
|
| Garantie |
60
|
|
