Placa de bază Gigabyte B760M AORUS ELITE AX LGA1700

Adăugați preferateAdăugat la lista de preferințeEliminat din lista de dorințe 0

Prețul inițial a fost: 1,135.25 lei.Prețul curent este: 1,007.50 lei.

Stoc epuizat

SKU: B760M A ELITE AX Categorie

Placa de baza Gigabyte B760M AORUS ELITE AX LGA1700, 4x sloturi RAM DDR5, max. 128GB, frecventa maxima suportata 7600MHz, 1x DisplayPort, 1x HDMI, 2x PCIe x16, 2x M.2, 4x conectori SATA 6GB/s, 1x LAN 1Gbps, WIFI 2.4Gbps, Bluetooth 5.3, microATX

Specificație: Placa de bază Gigabyte B760M AORUS ELITE AX LGA1700

PCI

0

Serial-or-Paralel

No/No

Video-Connection

HDMI/DP

Wi-FI

Yes

Onboard-CPU

No

RAID support

Yes

Component for

PC

Windows operating systems supported

Windows 10, Windows 11

Processor manufacturer

Intel

Top Wi-Fi standard

Wi-Fi 6E (802.11ax)

WLAN controller model

Intel Wi-Fi 6E AX211

Ethernet LAN

Yes

HDMI ports quantity

1

USB 3.2 Gen 2x2 Type-C ports quantity

1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

0

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity

0

USB 2.0 ports quantity

4

Audio output channels

7.1 channels

PCI Express x16 (Gen 4.x) slots

1

Supported storage drive types

HDD & SSD

Number of M.2 (M) slots

2

Maximum internal memory

192 GB

HDCP

Yes

DisplayPorts quantity

1

VGA (D-Sub) ports quantity

0

DVI-D ports quantity

0

DirectX version

12.0

Parallel processing technology support

CrossFireX

Model Chipset

B760

Gaming

Nu

Format:

Micro-ATX (mATX)

Soclu Procesor

Socket 1700

Tip Memorie

DDR5

Numar sloturi memorie

4

Memorie maxima

128 GB

Tip slot interfata grafica

PCIe 4.0 x16

Chipset audio integrat

Realtek

Canale audio

7.1

Wireless

Da

Bluetooth

Da

USB Type-C

Da

HDMI

Da

Thunderbolt

Nu

Sloturi M.2

2

RJ-45 LAN

1

Number of memory slots

4

Memory slots type

DIMM

Unbuffered memory

Yes

Supported storage drive interfaces

M.2, SATA III

USB 2.0 connectors

2

USB 3.2 Gen 1 (3.1 Gen 1) connectors

1

Number of SATA III connectors

4

Front panel audio connector

Yes

ATX Power connector (24-pin)

Yes

CPU fan connector

Yes

EPS power connector (8-pin)

Yes

Motherboard form factor

micro ATX

BIOS type

UEFI AMI

BIOS memory size

256 Mbit

Clear CMOS jumper

Yes

Supported memory types

DDR5-SDRAM

Number of HDDs supported

4

RAID levels

0, 1, 5, 10

USB 3.2 Gen 2 (3.1 Gen 2) connectors

1

Front panel connector

Yes

TPM connector

Yes

RGB LED pin header

Yes

WiFi-AP antenna jack

2

Motherboard chipset family

Intel

PC health monitoring

Fan, Temperature, Voltage, Water cooling

ACPI version

5.0

Desktop Management Interface (DMI) version

2.7

System Management BIOS (SMBIOS) version

2.7

Lithium weight per battery

0.07 g

Processor socket

LGA 1700

Supported processor sockets

LGA 1700

Maximum internal memory supported by processor

192 GB

Maximum resolution

4096 x 2304 pixels

Total number of SATA connectors

4

Thunderbolt headers

2

ECC сompatibility

Non-ECC

Number of storage drives supported

6

S/PDIF out connector

Yes

Supported memory module capacities

1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 32GB, 48GB

Motherboard chipset

Intel B760 Express

Bundled software

Norton Internet Security

Peripheral (Molex) power connectors (4-pin)

1

Number of chassis fan connectors

3

Supported memory clock speeds

4000,4800,5300,5400,5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800 MHz

Ethernet interface type

2.5 Gigabit Ethernet, 5 Gigabit Ethernet

Microphone in

Yes

Headphone outputs

1

Bluetooth version

5.3

Height

35 mm

Cables included

SATA

Width

244 mm

Depth

244 mm

Country of origin

China

Package height

68 mm

Power source type

ATX

Battery weight

3 g

Number of battery cells

1

Battery technology

Lithium-Manganese Dioxide (LiMnO2)

Battery type

CR2032

Package width

270 mm

Package depth

268 mm

Package weight

1.56 kg

Producator

GIGABYTE

Garantie

36
