Name: Placa de bază ASUS TUF B760-PLUS DDR5 WIFI LGA1700 - A.W.P.S Store
Brand: ASUS
SKU: TUF B760-PLUS WIFI
Price: 1176.76 RON
Availability: OutOfStock

Placa de bază ASUS TUF B760-PLUS DDR5 WIFI LGA1700

Adăugați preferateAdăugat la lista de preferințeEliminat din lista de dorințe 0

Placa de baza ASUS TUF B760-PLUS DDR5 WIFI LGA1700

Specificație: Placa de bază ASUS TUF B760-PLUS DDR5 WIFI LGA1700

PCI	0
Serial-or-Paralel	No/No
Video-Connection	HDMI/DP
Wi-FI	Yes
Onboard-CPU	No
RAID support	Yes
Component for	PC
Windows operating systems supported	Windows 10, Windows 11
DisplayPort version	1.4
Memory channels	Dual-channel
Processor manufacturer	Intel
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Ethernet LAN	Yes
HDMI ports quantity	1
HDMI version	2.1
Maximum internal memory	128 GB
USB 2.0 ports quantity	2
USB 3.2 Gen 2x2 Type-C ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
PCI Express x1 (Gen 3.x) slots	2
Audio output channels	7.1 channels
Line-in	Yes
PCI Express x16 (Gen 5.x) slots	1
PCI Express x16 (Gen 4.x) slots	1
On-board graphics card	No
Supported storage drive types	HDD & SSD
Cooling type	Passive
VGA (D-Sub) ports quantity	1
DisplayPorts quantity	1
Parallel processing technology support	Not supported
DVI-D ports quantity	0
Model Chipset	B760
Gaming	Da
Format:	ATX
Soclu Procesor	Socket 1700
Tip Memorie	DDR5
Numar sloturi memorie	4
Memorie maxima	128 GB
Tip slot interfata grafica	PCIe 5.0 x16
Chipset audio integrat	Realtek
Canale audio	7.1
Wireless	Da
Bluetooth	Da
USB Type-C	Da
HDMI	Da
Thunderbolt	Nu
Sloturi M.2	3
RJ-45 LAN	1
Number of memory slots	4
Memory slots type	DIMM
Unbuffered memory	Yes
USB 2.0 connectors	2
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Number of SATA III connectors	4
Number of SATA II connectors	0
Number of SATA connectors	0
Front panel audio connector	Yes
ATX Power connector (24-pin)	Yes
CPU fan connector	Yes
EPS power connector (8-pin)	Yes
BIOS type	UEFI AMI
Supported memory types	DDR5-SDRAM
Number of HDDs supported	4
Number of storage drives supported	7
RAID levels	0, 1, 5, 10
Front panel connector	Yes
TPM connector	Yes
RGB LED pin header	Yes
Ethernet interface type	2.5 Gigabit Ethernet
Motherboard form factor	ATX
Motherboard chipset family	Intel
Number of M.2 (M) slots	3
Processor socket	LGA 1700
Maximum number of SMP processors	1
Supported processor sockets	LGA 1700
12V power connector	Yes
ECC сompatibility	Non-ECC
S/PDIF out connector	Yes
Number of COM connectors	1
Motherboard chipset	Intel B760
BIOS memory size	128 Mbit
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
Thunderbolt headers	1
Peripheral (Molex) power connectors (4-pin)	1
Number of chassis fan connectors	3
PCI slots	4
Supported memory clock speeds	5066 MHz
Compatible processor series	Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7
Supported storage drive interfaces	M.2, PCI Express 3.0, PCI Express 5.0, SATA III
Headphone outputs	1
Bluetooth version	5.2
Cables included	SATA
Width	305 mm
Depth	244 mm
Package height	53 mm
Power source type	ATX
Package width	328 mm
Package weight	1.16 kg
Package depth	266 mm
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Producator	ASUS
Garantie	36
