Placa de bază ASUS ProArt B650-CREATOR AM5

Adăugați preferateAdăugat la lista de preferințeEliminat din lista de dorințe 0

Placa de baza Asus AMD ProArt B650-CREATOR AM5 DDR5, 4x DDR5 6400MHz, 1x HDMI, 1x Type-C, 3x PCIe x16, 1x PCIe x1, 3x M.2, 4x SATA 6Gb/s, ATX

Specificație: Placa de bază ASUS ProArt B650-CREATOR AM5

PCI	0
Serial-or-Paralel	No/No
Video-Connection	HDMI
Wi-FI	No
Onboard-CPU	No
RAID support	Yes
Component for	PC
DisplayPort version	1.4
Memory channels	Dual-channel
Ethernet LAN	Yes
HDMI ports quantity	1
HDMI version	2.1
Maximum internal memory	128 GB
Processor manufacturer	AMD
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
Audio output channels	7.1 channels
Line-in	Yes
Supported storage drive types	HDD & SSD
S/PDIF out port	Yes
DisplayPorts quantity	1
VGA (D-Sub) ports quantity	0
Parallel processing technology support	Not supported
DVI-D ports quantity	0
Windows operating systems supported	Windows 10, Windows 11 x64
Model Chipset	B650
Gaming	Nu
Format:	ATX
Soclu Procesor	Socket AM5
Tip Memorie	DDR5
Numar sloturi memorie	4
Memorie maxima	128 GB
Tip slot interfata grafica	PCIe 4.0 x16
Chipset audio integrat	Realtek
Canale audio	7.1
Wireless	Nu
Bluetooth	Nu
USB Type-C	Da
HDMI	Da
Thunderbolt	Nu
Sloturi M.2	3
RJ-45 LAN	2
Number of memory slots	4
Memory slots type	DIMM
Unbuffered memory	Yes
Supported storage drive interfaces	M.2, SATA III
USB 2.0 connectors	2
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
Number of SATA III connectors	4
Front panel audio connector	Yes
ATX Power connector (24-pin)	Yes
CPU fan connector	Yes
EPS power connector (8-pin)	Yes
Motherboard chipset family	AMD
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
Supported memory types	DDR5-SDRAM
ECC сompatibility	ECC & Non-ECC
USB 3.2 Gen 2 (3.1 Gen 2) connectors	1
Number of chassis fan connectors	4
RGB LED pin header	Yes
Motherboard form factor	ATX
Number of M.2 (M) slots	3
12V power connector	Yes
Number of COM connectors	1
PCI Express x16 (Gen 4.x) slots	3
Thunderbolt headers	1
Back-to-BIOS button	Yes
RAID levels	0, 1, 10
Processor socket	Socket AM5
Supported processor sockets	Socket AM5
Supported memory clock speeds	6400 MHz
Compatible processor series	AMD Ryzen 7000 Series
Number of M.2 (E) slots	1
Motherboard chipset	AMD B650
Ethernet interface type	2.5 Gigabit Ethernet, Gigabit Ethernet
PCI Express x4 (Gen 1.x) slots	1
Microphone in	Yes
Headphone outputs	1
Ethernet LAN (RJ-45) ports	2
Cables included	SATA
Width	305 mm
Depth	244 mm
Power source type	ATX
Producator	ASUS
Garantie	36
